5050 Tunable White LED Strip Light 24V - 2-in-1 Chip - 5m - 335 lm/ft

Part Number: NFLS-TW300x3-IP20-24V

$ $56.95 In Stock

$56.95

write a review
90+CRI 24V 10mm


More Views





Stock Status: (over 500 in stock)



Please Choose:

Quantity Discounts (Wholesale Pricing)
Please send us an email

Discounts?

Our discount tiers are based on product price and quantity. The product price determines your tier.


Description

This tunable white LED strip light emits up to 335 lumens of powerful illumination per foot. Color temperature can be adjusted from 2700K to 6500K with a tunable white controller (sold separately). The 16.4' LED strip light operates on 24 VDC and can be used in longer runs than 12V strips. Easily cut it into separate 6-LED segments and install it with its peel-and-stick 3M™ adhesive backing. This strip is covered by a lifetime warranty. It's great for cabinets, under-cabinet lighting, toe-kicks, coves, bookshelves, or other indoor applications where space is limited.

Warranties & Certifications

TECHNICAL DETAILS

Beam Angle120 degreeLED Density18 LEDs/ft.
DimmableYesIP RatingNon-Weatherproof IP20
LED Lifetime50000 HoursLED quantity300 LEDs
Ambient Temperature-20~+45 °C (-4~+113 °F)Strip Width10mm (0.39in)
LED Type5050 SMDLEDs per Segment6
Total Length196.9in (16.40ft)Wire Length483mm (19in)
Color Temperature2700~6500 KLumen5495 Lumen
Operating Voltage Range24 VDCCRI80+
Standards And CertificationsCE/RoHS CompliantConnection TypePigtail /Wire Leads
Brightness335 lm/ft (1099 lm/m)Wattage Total69 Watts
All specifications are subject to change without notice.

Dimension:

Applications
Task Lighting, LED Sign Lighting, LED Backlights, Accent Lighting, Off Grid Lighting,
Retail Lighting, Automotive Accent Lighting, Cove Lighting, Under-Cabinet Lighting,
Bias Lighting, LED Display Case Lighting, Trade Show Lighting, TV backlighting.

Waterproof series
1:Non-waterproof LED Strip: PCB (Printed Circuit Board) with 3M self-adhesive back.--(For Indoor).
2:Waterproof LED Strip--Surface Injection  IP65: PCB surface is encapsulated with plastic Gel, with self-adhesive 3M back, --(For Outdoor & Indoor).
3:Waterproof LED Strip--Silicon Tube IP67: PCB is encapsulated with silicon tube, with plastic fastener,better waterproof, --(For Outdoor).
4:Waterproof LED Strip--Whole Injection IP68: PCB both surface and back are encapsulated with plastic Gel, with plastic fastener, top level of waterproof, --(For Outdoor).

Why choose LEDStripInHut LED Strip Light
1.PCB board: LEDStripInHut use at least 2 ounces pcb board, some are 3 ounces and 4 ounces for better dissipation. They are 100% pure copper. Our PCB board are CE, ROHS, UL listed.
2.LED Chip: LEDStripInHut mostly use Epistar brand led chips. We can do other brand chips according to customer’s request, for example, Cree, Samsung, Philips, San’an, Honglitronic and Smalite led chips. All of these led chips are in high quality. We only focus on high quality.
3.Color Rendering Index: LEDStripInHut use at least Ra80 led chips to do our led strip lights. When we test by the integrating sphere machine, it usually shows Ra83 for most of our led chips. We also use many Ra90 and Ra95 led chips for special projects. We can offer the test report for each batch of our led strip light.
4.Uniformity: LEDStripInHut always keep the same bin color temperature for all our led strip lights. It’s very important to our customers.
5.Waterproof Rating: We not only can offer traditional IP65, IP67, IP68 waterproof process, but also new silicone extrusion process for IP67, IP68 and silicone neon technique in dotless frosted encapsulations. Most of our waterproof mold are private mode.
6.Engineer Team: LEDStripInHut have our own engineer team. Whatever flexible strip pcb or rigid strip pcb, our engieer team can draw greber file for customers in the first time. We welcome all OEM and ODM orders from all over the world.
7.Service: Most of LEDStripInHut led strips are CE, ROHS, cUL and UL listed. We warranty 3-5 years. Welcome to visit our factory, or contact us: ledstripinhut@gmail.com
